| Automatic two-sided printing (Duplex) | No |
| Maximum number of input trays | 1 |
| Print technology | Inkjet |
| Maximum print/media format | A1 (594 mm) |
| Printer Interface | Network |
| Maximum print speed (A4 per minute) | 1 |
| Standard number of input trays | 1 |
| Actual printer resolution (in DPI) | 1200x2400 |
| Functions | Colour printing |
Click on the image to view the product tour from EPSON.
Flexible Production
Ink tanks with a volume of 110 ml/350 ml/700 ml
Banner Printing Concept Mode
Print A1 format posters in less than 24 seconds
Subtle Design
Thoughtful design suitable for any environment
Easy to use – wireless printing
From a computer or mobile device
Reliability Guarantee
Unique Nozzle Verification Technology (NVT) preventing the occurrence of faulty prints
| Technology | |
|---|---|
| Printing Method | PrecisionCore Print Head™ |
| Ink Technology | Pigment Ink, Ultrachrome® XD2 |
| Time to First Page | Black and White 25 s, Colour 25 s |
| Colors | Black [Pigment], Azure [Pigment], Yellow [Pigment], Purple [Pigment] |
| Colours Capacity | Black [110ml, 350ml, 700ml], Cyan [110ml, 350ml, 700ml], Yellow [110ml, 350ml, 700ml], Magenta [110ml, 350ml, 700ml] |
| Min. drop size | 4 tbsp, With variable droplet size ink technology |
| Minimum line width | 0,02 mm |
| Line accuracy | +/- 0.1 |
| Print from | PC, MAC, Mobilní zařízení, USB |
| Nozzle Configuration | 800 nozzles black, 800 Nozzles for each color |
| Print Resolution | 2.400 x 1.200 dpi |
| Paper/Media Handling | |
| Paper Formats | A1 (59,4x84,1 cm), A2 (42,0x59,4 cm), A2+, A3+, A3 (29,7x42,0 cm), A4 (21.0x29,7 cm), B1 (72,8x102,8 cm), B2 (51,4x72,8 cm), B3 (36,4cmx51,4 m), B4 (25,7x36,4 cm), B5 (17,6x25,7 cm), 17" (43,2 cm), 24" (61,0 cm) |
| Print margins of media in sheets | Mode 1: 3 mm (top), 3 mm (right), 20 mm (bottom), 3 mm (left) |
| Roll print margins | Mode 1: 3 mm (top), 3 mm (bottom) |
| Suitable paper thickness | 0,05 mm - 0,3 mm |
| General Information | |
| Energy Consumption | 38 W, 13 W (standby mode), 0,25 W (off) |
| Power Supply | AC 100 V - 240 V, 50 Hz - 60 Hz |
| Product Dimensions | 1.080? x 750 x 1.060 mm (width x depth x height) |
| Product Weight | 64 kg |
| Max. noise level | Operation: 7,5 B (A) Operation (Roll): 50 dB (A) in standby mode: 32 dB (A) |
| Printing from mobile devices and cloud printing | Apple AirPrint |
| Contents of Delivery | power cable, Driver and Utilities (CD), Individual ink cartridges, Maintenance Tank, Paper stacker, Printer Stand with stacking print basket, Installation guide, Spindle Unit(s), SureColor T-Series Printer, User manual (CD), Warranty documents |
| Optional extras | Document carrier sheet A0, Roll adapter, Cover Plus warranty extensions, Roll feed spindle 24" LFP |
| Additional Features | |
| Memory | Printer: 1 GB |
| compatible operating systems | Mac OS X 10.6.8 or later, Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
| Emulation | ESC/P-R, HP-GL2, RTL |
| Features and Properties | Touchscreen, Direct printing, Direct scanning to the printer without using a computer, Direct printing from USB |
| Scanner not included | Yes |
| Interface | USB 3.0, Gigabit Ethernet interface, IEEE 802 wireless LAN.11 b/g/n (WiFi 4), Wi-Fi Direct |
| Security | TLS, SSL, IEE 802, SNMP, IPSec, IPv6 |
| Media Handling | Automatic cutter, Borderless printing, Paper Rolls |
| Others | |
| Warranty | 24 months On-site Service |
| LCD and Memory Cards | |
| LCD display | Type: Color, Touch screen, Diagonal: 10,9 cm |
| Scanning | |
| Supported Models | Epson WorkForce DS-6500, Epson WorkForce DS-60000 |
| Output Formats | JPEG, TIFF, PDF, PDF/A |
